| Name: | 0.5mm 0.6mm 0.8mm 1mm 1.2mm 3mm Diameter Lead Free Solder Wire |
| Composition: | Tin, Cu, Ag |
| Diameter: | 0.5mm, 0.8mm, 1mm,2mm,3mm |
| Weight per roll: | 50g to 1000g |
| Place of Origin: | Foshan, China |
Product Description
Tin Lead Free Solder Welding Wire with Flux
Core No Clean high low melting OEM Factory Foshan China 0.5-1.0mm Sn/Cu/Ag for Lamp
Holder ROHS Environment
Tin Lead Free Solder Wires:
Our company produces Tin Lead Free Solder Wires for already 5years, including Sn/Cu、Sn/Ag、Sn/Sb、Sn/Ag/Cu.
Tin Lead Free Solder Wire Type of Alloy:
|
Alloy
composition (wt.%) |
Diameter |
Flux Content |
Weight / Roll |
Melting point℃ |
Working point |
Usage &
Application |
|||
|
Type |
Tin-Sn |
Silver-Ag |
Copper-Cu |
||||||
|
SAC305 |
96.50% |
3.00% |
0.50% |
0.8-3.0mm |
1.8-2.4% |
750-1000g |
217-219 |
280-320 |
LED, IT, PCB,
High-class electronics, Lighting industry, Radiators, Household appliance and
Precise Instruments, Audio and Sound System and other soldering |
|
SAC300 |
97.00% |
3.00% |
0% |
217-220 |
280-320 |
||||
|
SAC0307 |
99.00% |
0.30% |
0.70% |
217-225 |
260-320 |
||||
|
SAC07 |
99.30% |
0.00% |
0.70% |
227 |
260-280 |
||||
Type of Tin Lead Free Solder
Wire:
l No-clean solder wire
l Solid-core solder wire
l Dim solder wire
l Low temperature tin solder
wire
l High temperature tin solder
wire
l Nickel-plated solder wire
l Water-soluble solder wire
l Flux-cored solder wire
l Solder wire for lamp holder
l Multiple specifications for
option
Advantages of Tin Lead Free Solder
Wire:
l Environment protection, no
pollute
l Short wetting time, fine weld
ability
l No rosin splash
l Rosin distributes evenly and
continuity in the wire
l Little dross in welding head
l Solder wire won’t be snarled
when performs
l Wire roll appears trim, nice,
polished
l No smell, little smoke, without volatilizing gas
Soldering Technology of Tin Lead
Free Solder Wire
l Iron tip temperature should be
370℃~400℃
l Avoid excess heat input,
swifter action with the iron, staffs need trained
l Ferric power should be
60W~80W, with good temperature returning
Diameter of Tin Lead Free Solder
Wire:
0.6mm—3.0mm
Weight
of Tin Lead Free Solder Wire:
300g—600g
Lead time:
We have a lot of stock of Tin Lead Free Solder Wires, if not very big
quantity, we can send the goods as soon as possible after receive payment. If
big quantity, 15days after order confirmed.
Shipping term:
If small quantities of tin lead solder wire, usually send by courier (DHL,
FEDEX, TNT and so on).If big quantity, we are advice to ship by air or by sea.
We are near Foshan, Ronggui port.
Packing:
Solder wire is packaged on spools,10 spools of tin lead solder wire per box
Neutral packing or OEM packing is available
Spectrum Analyzer:
Technical support to help customers to analyse their samples, and send out
report.
